Superior Bass Superior Power
Superior bass requires superior power and the Linertec LT-3900 car audio monoblock amplifier was engineered just for that. With a power output of 2500 watts RMS at 1ohm, this Linertec monoblock amplifier is compatible with a wide range of subwoofer configurations and will reliably power them for some serious vibes.
The Linertec LT-3900 doesn’t just offer big and reliable power. The ability to refine and control output signal is just as important to get that bass sounding just right. Which is why the Linertec LT-3900 is designed with a variety of controls which allow you to tune the amp's signal for optimal subwoofer efficiency and tone. The low-pass and subsonic filters clear the way for smooth bass sound, while a variable bass boost lets you dial up the wallop when you need it.
Features
- 1 Channel car audio power amplifier
- Bass boost control
- Subsonic control
- Low level input
- Gain control
- LED power and protection indicator
- Remote turn-on/turn-off
- Short circuit protection
- Mosfet power supply
- Thermal protection
Technical Specifications
| Parameter |
Specification |
| Amplifier Class |
D Class |
| Supply Voltage |
11~15V DC |
| RMS Power Output @ 4 Ohm |
1000W RMS x 1 Channel |
| RMS Power Output @ 2 Ohm |
1700W RMS x 1 Channel |
| RMS Power Output @ 1 Ohm |
2500W RMS x 1 Channel |
| Frequency Response (±3dB) |
17Hz~180Hz |
| Signal to Noise Ratio |
90dB |
| Input Impedance |
20K Ohm |
| Input Sensitivity |
100mV~6V |
| Total Harmonic Distortion |
<0.05% |
| RCA Input |
1 Channel |
| Subsonic |
17Hz-50Hz |
| Bass Frequency |
30Hz-80Hz |
| Low Pass Frequency |
50Hz-400Hz |
| Bass Boost |
0~12dB |
| Recommended Fuse Type |
T.B.A |
| Weight |
T.B.A |
| Dimensions (LxWxH) |
T.B.A |
